#8 x 2- Wood Screws
Connects SHELF JOIST to SHELF FRONT
end.
F20.10
F20.11
D: From top of (1132) Shelf Front measure 5/8” (1.59 cm) down then on the front and right side place one
Screws. (F20.9, F20.10 and F20.11)
Step 20: Lower Shelf Assembly - Back Wall
Part 4
F20.9
#8 x 2- Wood Screws
Connects SHELF JOIST to SHELF FRONT
end.
#8 x 2- Wood Screws
Connects SHELF JOIST to SHELF FRONT
end.
Inside View
Hardware
3 x #8 x 2” Wood Screw
Wood Parts
1 x (1135) Shelf Joist
#8 x 2”
Wood Screw
(1132) Shelf Front
5/8”
(1.59 cm)
(1132) Shelf Front
(1135) Shelf Joist
(1135) Shelf Joist
(in front)
#8 x 2”
Wood Screw
Flush
Roof removed
for clarity
To Next Page
