#8 x 2-1/2”- Wood Screws
Connects SHELF GUSSET to
SHELF JOIST.
PRODUCE 2 SETS OF THESE
PARTS
#10 X 1-1/4” Pan Screws
Connects CORNER BRACKET
to SHELF JOIST.
F21.10
E: Flush to one side of one (1135) Shelf Joist attach one Corner Bracket with one #10 x 1-1/4” Pan Screw.
(F21.10)
F: Flush to the other side of (1135) Shelf Joist attach one (1134) Shelf Gusset with one #8 x 2-1/2” Wood
Screw. (F21.10)
Hardware
1 x #10 x 1-1/4” Pan Screw
1 x #8 x 2-1/2” Wood Screw
Wood Parts
1 x (1135) Shelf Joist
1 x (1134) Shelf Gusset
Components
1 x Corner Bracket
#10 x 1-1/4”
Pan Screw
Corner
Bracket
#8 x 2-1/2”
Wood Screw
(1135) Shelf Joist
Flush
Flush
(1134) Shelf Gusset
Step 21: Lower Shelf Assembly - Side Wall
Part 4
To Next Page
