Fig. 13.4
Hardware
16 x #8 x 1” Pan Screw
Componets:
4 x Tie Centre Bracket
#8 x 1”
Pan Screw
Step 13: Truss Assemblies
Part 2
Tight
Tie Centre
Bracket
Roof Panel
removed for
clarity
#8 x 1” Pan
Screw
Fig. 13.3
C: Attach one Tie Centre Bracket to the peak of ve rafters, (541) Ridge Long, (542) Ridge Short with four #8
x 1” Pan Screws per bracket. Notice that three Tie Centre Brackets face one way and one faces the opposite
direction. It will only t on this side. (g. 13.3 and 13.4)
Notice Tie Centre
Bracket on opposite
side for this location
(541)
Ridge
Long
(542)
Ridge
Short
Rafter
Rafter
This bracket does
not get installed until
Step 13, Part 4
To Next Page
