YASKAWA A1000 Product Replacement Guide

VAN-V17001E<1>, Replacing A1000 crane with CR700
17/44
Model
Drive Capacity
A1000: Model
CR700: Catalog
code
Terminal
Symbol
Applicable
Gauge
mm
2
Terminal Screw㻌
Tightening
Torque
N㺃m㻌
Size㻌 Shape㻌
A1000 CIMR-AA2A0040
R/L1,S/L2,T/L3 14
M4 Panhead (+) 2.1 - 2.3
U/T1,V/T2,W/T3㻌 8-14㻌
-,+1,+2㻌 14㻌
B1,B2㻌 3.5 - 5.5㻌
肀㻌
5.5 - 8㻌 M5 +/- screw 2.0 - 2.5
CR700 CR70A2033
R/L1,S/L2,T/L3 2 - 14
M4
Slot (-)
1.5 - 1.7
U/T1,V/T2,W/T3㻌 2-14㻌
-,+1,+2㻌 2-22㻌 M5 2.3 - 2.5
B1,B2㻌 2-5.5㻌 M4 1.5 - 1.7
肀㻌
5.5 - 8㻌 M5 +/- screw 2.0 - 2.5
A1000 CIMR-AA2A0056
R/L1,S/L2,T/L3 14 - 22
M6
Hexagon bolt
(with Phillips
screwhead)
5.4 - 6.0
U/T1,V/T2,W/T3㻌 14 - 22㻌
-,+1,+2㻌 14 - 22㻌
B1,B2㻌 5.5 - 14㻌 M5 Panhead (+) 2.7 - 3.0
肀㻌
8-14㻌 M6 +/- screw 5.4 - 6.0
CR700 CR70A2047
R/L1,S/L2,T/L3 2 - 22
M5 Slot (-) 2.3 - 2.5
U/T1,V/T2,W/T3㻌 2-14㻌
-,+1,+2㻌 2-38㻌 M6
Hex socket
cap
(WAF: 5 mm)
5-5.5
B1,B2㻌 2-14㻌 M4 Slot (-) 1.5 - 1.7
肀㻌
8-14㻌 M6 +/- screw 5.4 - 6.0
A1000 CIMR-AA2A0069
R/L1,S/L2,T/L3 22 - 30㻌
M8㻌
Hexagon bolt
(with Phillips
screwhead)
9.9 - 11㻌
U/T1,V/T2,W/T3㻌 14 - 30㻌
-,+1,+2㻌 22 - 30㻌
B1,B2㻌 8-14㻌 M5㻌 Panhead (+) 2.7 - 3.0
肀㻌
8-22㻌 M6㻌 +/- screw 5.4 - 6.0
CR700 CR70A2060
R/L1,S/L2,T/L3 2 - 38㻌
M6㻌
Hex socket
cap
(WAF: 5 mm)
5-5.5
U/T1,V/T2,W/T3㻌 2-22㻌
-,+1,+2㻌 2-50㻌
B1,B2㻌 2-14㻌 M4 Slot (-) 1.5 - 1.7
肀㻌
8-22㻌 M6 +/- screw 5.4 - 6.0

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
