YASKAWA A1000 Product Replacement Guide

VAN-V17001E<1>, Replacing A1000 crane with CR700
18/44
Model
Drive Capacity
A1000: Model
CR700: Catalog
code
Terminal
Symbol
Applicable
Gauge
mm
2
Terminal Screw㻌
Tightening
Torque
N㺃m㻌
Size㻌 Shape㻌
A1000 CIMR-AA2A0081
R/L1,S/L2,T/L3 30 - 38㻌
M8㻌
Hexagon bolt
(with Phillips
screwhead)
9.9 - 11㻌
U/T1,V/T2,W/T3㻌 22 - 38㻌
-,+1,+2㻌 30 - 38㻌
B1,B2㻌 14㻌 M5㻌 Panhead (+) 2.7 - 3.0
肀㻌
14 - 22㻌 M6㻌 +/- screw 5.4 - 6.0
CR700 CR70A2075
R/L1,S/L2,T/L3 2 - 50㻌
M6㻌
Hex socket
cap
(WAF: 5 mm)
5-5.5
U/T1,V/T2,W/T3㻌 2-30㻌
-,+1,+2㻌 2-60㻌
B1,B2㻌 2-14㻌 M4 Slot (-) 1.5 - 1.7
肀㻌
14 - 22㻌 M6 +/- screw 5.4 - 6.0
A1000 CIMR-AA2A0110
R/L1,S/L2,T/L3 30 - 50㻌
M8㻌
Hexagon bolt
(with Phillips
screwhead)㻌
9.0 - 11㻌
U/T1,V/T2,W/T3㻌 30 - 50㻌
-,+1㻌 38 - 60㻌
B1,B2㻌 14 - 50㻌
肀㻌
14 - 38㻌 Minus (-)㻌
CR700 CR70A2088
R/L1,S/L2,T/L3 22 - 38㻌
M6㻌
Hex socket
cap
(WAF: 5 mm)㻌
8-9㻌
U/T1,V/T2,W/T3㻌 22 - 38㻌
-,+1㻌 30 - 60㻌 M8㻌
Hex socket
cap
(WAF: 6 mm)㻌
10 - 12㻌
B1,B2㻌 8-22㻌 M6㻌 Minus (-)㻌 3-3.5㻌
肀㻌
14 - 38㻌 M6㻌
Hexagon bolt
(+)
㻌
5.4 – 6.0㻌
A1000 CIMR-AA2A0138
R/L1,S/L2,T/L3 50 - 60㻌
M10㻌
Hexagon bolt
(with Phillips
screwhead)㻌
18 - 23㻌
U/T1,V/T2,W/T3㻌 50 - 60㻌
-,+1㻌 60 - 80㻌
B1,B2㻌 22 - 60㻌
肀㻌
22 - 38㻌 M8㻌 Minus (-)㻌 9.0 - 11㻌
CR700 CR70A2115
R/L1,S/L2,T/L3 22 - 60㻌
M6㻌
Hex socket
cap
(WAF: 5 mm)㻌
8-9㻌
U/T1,V/T2,W/T3㻌 22 - 60㻌
-,+1㻌 30 - 80㻌 M8㻌
Hex socket
cap
(WAF: 6 mm)㻌
10 - 12㻌
B1,B2㻌 8-30㻌 M6㻌 Minus (-)㻌 3-3.5㻌
肀㻌
22 - 38㻌 M6㻌
Hexagon bolt
(+)㻌
5.4 – 6.0㻌

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
