YASKAWA A1000 Product Replacement Guide

VAN-V17001E<1>, Replacing A1000 crane with CR700
19/44
Model
Drive Capacity
A1000: Model
CR700: Catalog
code
Terminal
Symbol
Applicable
Gauge
mm
2
Terminal Screw㻌
Tightening
Torque
N㺃m㻌
Size㻌 Shape㻌
A1000 CIMR-AA2A0169
R/L1,S/L2,T/L3 60 - 100㻌
M10㻌
Hexagon bolt
(with Phillips
screwhead)㻌
18 - 23㻌
U/T1,V/T2,W/T3㻌 60 - 100㻌
-,+1㻌 50 - 100㻌
+3㻌 50 - 100㻌
肀㻌
22 - 60㻌 Minus (-)㻌
CR700 CR70A2145
R/L1,S/L2,T/L3 50 - 100㻌
M10㻌
Hex socket
cap
(WAF: 8 mm)㻌
12 - 14㻌
U/T1,V/T2,W/T3㻌 50 - 125㻌
-,-,+1,+1㻌 22 - 50㻌 M6㻌
Hex socket
cap
(WAF: 5 mm)㻌
8-9㻌
+3㻌 30 - 80㻌 M8㻌
Hex socket
cap
(WAF: 6 mm)㻌
8-9㻌
肀㻌
22 - 60㻌 M8㻌
Hexagon bolt
with slot㻌
9.0 - 11㻌
A1000 CIMR-AA2A0211
R/L1,S/L2,T/L3 80 - 100㻌
M10㻌
Hexagon bolt
(with Phillips
screwhead)㻌
18 - 23㻌
U/T1,V/T2,W/T3㻌 50 - 100㻌
-,+1㻌 50 - 100㻌
+3㻌 60 - 100㻌
肀㻌
22 - 60㻌 Minus (-)㻌
CR700 CR70A2180
R/L1,S/L2,T/L3 50 - 100㻌
M10㻌
Hex socket
cap
(WAF: 8 mm)㻌
12 - 14㻌
U/T1,V/T2,W/T3㻌 50 - 125㻌
-,-,+1,+1㻌 22 - 50㻌 M6㻌
Hex socket
cap
(WAF: 5 mm)㻌
8-9㻌
+3㻌 30 - 80㻌 M8㻌
Hex socket
cap
(WAF: 6 mm)㻌
8-9㻌
肀㻌
22 - 60㻌 M8㻌
Hexagon bolt
with slot㻌
9.0 - 11㻌
A1000 CIMR-AA2A0250
R/L1,S/L2,T/L3 38 - 150㻌
M12㻌
Hexagon bolt
(with Phillips
screwhead)㻌
32 - 40㻌
U/T1,V/T2,W/T3㻌 38 - 150㻌
-,+1㻌 80 - 150㻌
+3㻌 30 - 150㻌 M10㻌 18 - 23㻌
肀㻌
22 - 150㻌 M12㻌 Minus (-)㻌 32 - 40㻌
CR700 CR70A2215
R/L1,S/L2,T/L3 22 - 100x2P㻌
M10㻌
Hexagon bolt
and Nut㻌
20㻌
U/T1,V/T2,W/T3㻌 22 - 100x2P㻌
-,+1㻌 30 - 125x2P㻌
+3㻌 22 - 60x2P㻌
肀㻌
22 - 200㻌 M10㻌
Hexagon bolt
with slot㻌
18 - 23㻌

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
