YASKAWA A1000 Product Replacement Guide

VAN-V17001E<1>, Replacing A1000 crane with CR700
20/44
Model
Drive Capacity
A1000: Model
CR700: Catalog
code
Terminal
Symbol
Applicable
Gauge
mm
2
Terminal Screw㻌
Tightening
Torque
N㺃m㻌
Size㻌 Shape㻌
A1000 CIMR-AA2A0312
R/L1,S/L2,T/L3 70 - 150㻌
M12㻌
Hexagon bolt
(with Phillips
screwhead)㻌
32 - 40㻌
U/T1,V/T2,W/T3㻌 70 - 200㻌
-,+1㻌 80 - 150㻌
+3㻌 80 - 150㻌 M10㻌 18 - 23㻌
肀㻌
38 - 150㻌 M12㻌 Minus (-)㻌 32 - 40㻌
CR700 CR70A2283
R/L1,S/L2,T/L3 22 - 100x2P㻌
M10㻌
Hexagon bolt
and Nut㻌
20㻌
U/T1,V/T2,W/T3㻌 22 - 100x2P㻌
-,+1㻌 30 - 125x2P㻌
+3㻌 22 - 60x2P㻌
肀㻌
38 - 200㻌 M10㻌
Hexagon bolt
with slot㻌
18 - 23㻌
A1000 CIMR-AA2A0360
R/L1,S/L2,T/L3 80 - 325㻌
M12㻌
Hexagon bolt
(with Phillips
screwhead)㻌
32 - 40㻌
U/T1,V/T2,W/T3㻌 80 - 325㻌
-,+1㻌 125 - 325㻌
+3㻌 80 - 325㻌 M10㻌 18 - 23㻌
肀㻌
38 - 200㻌 M12㻌 Minus (-)㻌 32 - 40㻌
CR700 CR70A2346
R/L1,S/L2,T/L3 60 - 125x2P㻌
M12㻌
Hexagon bolt
and Nut㻌
35㻌
U/T1,V/T2,W/T3㻌 60 - 125x2P㻌
-,+1㻌 100 - 150x2P㻌
+3㻌 38 - 150x2P㻌
肀㻌
38 - 200㻌 M12㻌
Hexagon bolt
with slot㻌
32 - 40㻌
A1000 CIMR-AA2A0415
R/L1,S/L2,T/L3 100 - 325㻌
M12㻌
Hexagon bolt
(with Phillips
screwhead)㻌
32 - 40㻌
U/T1,V/T2,W/T3㻌 125 - 325㻌
-,+1㻌 150 - 325㻌
+3㻌 80 - 325㻌 M10㻌 18 - 23㻌
肀㻌
60 - 200㻌 M12㻌 Minus (-)㻌 32 - 40㻌
CR700 CR70A2415
R/L1,S/L2,T/L3 60 - 125x2P㻌
M12㻌
Hexagon bolt
and Nut㻌
35㻌
U/T1,V/T2,W/T3㻌 60 - 125x2P㻌
-,+1㻌 100 - 150x2P㻌
+3㻌 38 - 150x2P㻌
肀㻌
60 - 200㻌 M12㻌
Hexagon bolt
with slot㻌
32 - 40㻌
