YASKAWA A1000 Product Replacement Guide

VAN-V17001E<1>, Replacing A1000 crane with CR700
22/44
Model
Drive Capacity
A1000: Model
CR700: Catalog
code
Terminal Symbol
Applicable
Gauge
mm
2
Terminal Screw㻌
Tightening
Torque
N•m㻌
Size㻌 Shape㻌
A1000 CIMR-AA4A0031㻌
R/L1,S/L2,T/L3 5.5 - 14
M5
Hexagon bolt
(with Phillips
screwhead)
3.6 - 4.0
U/T1,V/T2,W/T3 5.5 - 8
-,+1,+2 5.5 - 14
B1,B2 2 - 8 M5 Panhead (+) 2.7 - 3.0
肀
5.5 - 8 M6 +/- screw 5.4 - 6.0
CR700 CR70A4024㻌
R/L1,S/L2,T/L3 2 - 22
M5 Slot (-) 2.3 - 2.5
U/T1,V/T2,W/T3 2 - 14
-,+1,+2 2 - 38 M6
Hex socket
cap
(WAF: 5 mm)
5-5.5
B1,B2 2 - 14 M4 Slot (-) 1.5 - 1.7
肀
5.5 - 14 M6 +/- screw 5.4 - 6.0
A1000 CIMR-AA4A0038
R/L1,S/L2,T/L3 14
M5
Hexagon bolt
(with Phillips
screwhead)
3.6 - 4.0
U/T1,V/T2,W/T3 8 - 14
-,+1,+2 14
B1,B2 3.5 - 8 M5 Panhead (+) 2.7 - 3.0
肀
5.5 - 14 M6 +/- screw 5.4 - 6.0
CR700 CR70A4031
R/L1,S/L2,T/L3 2 - 22
M5 Slot (-) 2.3 - 2.5
U/T1,V/T2,W/T3 2 - 14
-,+1,+2 2 - 38 M6
Hex socket
cap
(WAF: 5 mm)
5-5.5
B1,B2 2 - 14 M4 Slot (-) 1.5 - 1.7
肀
5.5 - 14 M6 +/- screw 5.4 - 6.0
A1000 CIMR-AA4A0044
R/L1,S/L2,T/L3 14 - 22㻌
M6㻌
Hexagon bolt
(with Phillips
screwhead)
5.4 - 6.0㻌
㻌
U/T1,V/T2,W/T3! 14 - 22㻌
-,+1,+2! 14 - 22㻌
B1,B2! 5.5 - 8㻌 M5㻌 Panhead (+) 2.7 - 3.0
肀!
8-14㻌 M6㻌 +/- screw㻌 5.4 - 6.0
CR700 CR70A4039
R/L1,S/L2,T/L3 2 - 14㻌
M5㻌
Slot (-)㻌
2.3 - 2.5㻌
U/T1,V/T2,W/T3! 2-14㻌
-,+1,+2㻌 2-22㻌
B1,B2㻌 2-8㻌 M4㻌 1.5 - 1.7
肀㻌
8-22㻌 M6㻌 +/- screw㻌 5.4 - 6.0

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
