4 OPERATION
51
Step
Description Key Sequence Digital Operator Display
Setting completed.
:
• Return to constant No. display.
DSPL
• Move to tuning mode (T1-02).
RESET
• Verify the set value.
DATA
ENTER
• Change the value to “02” (tuning mode).
RESET
• Write-in the value.
DATA
ENTER
Displays for 0.5 seconds.
Setting completed.
• Return to drive mode.
DRIVE
PRGM
3
Adjustment start
RUN
Automatic adjustment during blinking
4
Adjustment completed
Displays for 2 seconds.
G
Adjustment completed.
Note: After verifying the set value of C2-13, write the value in Table A-7 in APPENDIX 5.
To Next Page
