12.6 AC/DC Reactors
12.6.1 Using a Three-Phase, 200-VAC Power Supply Input
12-28
12.6 AC/DC Reactors
Use the Reactors listed in the following tables if harmonic suppression is required.
12.6.1 Using a Three-Phase, 200-VAC Power Supply Input
Selection Table
 Σ-7S SERVOPACKs
* The last digit of an RoHS-compliant serial number is R. Consult Yaskawa Controls Co., Ltd. for RoHS-compliant
reactors.
 Σ-7W SERVOPACKs and Σ-7C SERVOPACKs
* The last digit of an RoHS-compliant serial number is R. Consult with Yaskawa Controls Co., Ltd. for RoHS-compli-
ant reactors.
SERVOPACK DC Reactor
Maximum
Applicable Motor
Capacity [kW]
Model
SGD7S-
Order
Num-
ber*
Induc-
tance
[mH]
Rated
Current
[Arms]
Mass
Ter mi na l
Screw
Size
Wire Size Inquiries
0.05 R70A
X5061 2.0 4.8 0.5 kg M4
AWG16
(1.25 mm
2
)
Yaskawa
Controls
Co., Ltd.
0.1 R90A
0.2 1R6A
0.4 2R8A
0.5 3R8A
0.75 5R5A
1.0 7R6A
1.5 120A
X5060 1.5 8.8 1.0 kg M4
AWG14
(2.0 mm
2
)
2.0 180A
AWG10
(5.5 mm
2
)
3.0 200A X5059 1.0 14.0 1.1 kg M5
5.0 330A X5068 0.47 26.8 1.9 kg M6
AWG8
(8.0 mm
2
)
6.0 470A X008025 0.49 28.3 2.6 kg M6
AWG8
(8.0 mm
2
)
7.5 550A X008026 0.43 35.5 2.9 kg M6
AWG6
(14.0 mm
2
)
11 590A X008027 0.32 49.7 3.5 kg M6
AWG3
(30.0 mm
2
)
15 780A X008028 0.26 72.6 4.0 kg M6
SERVOPACK DC Reactor
Maximum
Applicable Motor
Capacity [kW]
Model
SGD7W-
SGD7C-
Order
Num-
ber*
Induc-
tance
[mH]
Rated
Current
[Arms]
Mass
Ter mi na l
Screw
Size
Wire Size Inquiries
0.2 1R6A
X5061 2.0 4.8 0.5 kg M4
AWG16
(1.25 mm
2
)
Yaskawa
Controls
Co., Ltd.
0.4 2R8A
0.75 5R5A
X5060 1.5 8.8 1.0 kg M4
AWG14
(2.0 mm
2
)
1.0 7R6A
AWG10
(5.5 mm
2
)
