3.6 User-Assembled Wiring Materials for Encoder Cables
3.6.3 Cables without Connectors
3
Cables and User-Assembled Wiring Materials for SGM7J Rotary Servomotors
3-15
* A Crimping Tool is required. When using other wire sizes, contact the connector manufacturer for crimping tools.
 Cable Relay Connectors
3.6.3 Cables without Connectors
* Replace the boxes () in the order number with the cable length (05, 10, 15, or 20).
External Dimensions
[mm]
 Cable Installed away from Load
 Cable Installed toward Load
Order Number JZSP-CMP9-2-E
Manufacturer Molex Incorporated
Components 54280-0609 (soldered)
Product Specifications PS-54280
External Dimensions
[mm]
Continued from previous page.
Pin 6
Pin 1
Pin 9
Pin 7
(27.5)
17
20.5
2 × M2
pan-head screws
Motor mounting surface
25°
2 × M2 pan-head screws
(27.5)
20.5
17
Motor mounting
surface
Pin 6
Pin 1
25°
Pin 9
Pin 7
1
2
3
4
5
6
(19)
(12)
(44)
Item Standard Cable Flexible Cable
Order Number*
JZSP-CMP09--E
(maximum length: 20 m)
JZSP-CSP39--E
(maximum length: 20 m)
Specifications
UL20276 (rated temperature: 80°C)
AWG22 × 2C + AWG24 × 2P
UL20276 (rated temperature: 80°C)
AWG22 × 2C + AWG24 × 2P
AWG22 (0.33 mm
2
)
Outer diameter of insulating sheath:
1.15 mm
AWG22 (0.33 mm
2
)
Outer diameter of insulating sheath:
1.35 mm
AWG24 (0.20 mm
2
)
Outer diameter of insulating sheath:
1.09 mm
AWG24 (0.20 mm
2
)
Outer diameter of insulating sheath:
1.21 mm
Finished Diameter 6.5 mm 6.8 mm
Internal Structure and
Lead Colors
Light blue
/white
Orange
Orange
/white
Light
blue
Red
Black
Black
/light blue
Red
/light blue
Black
/pink
Red
/pink
Orange
Light
green
