Capacity Related Parameters B - 4
* Default and maximum carrier frequency value when C6-01=2 (Normal Duty 2)
* Default and maximum carrier frequency value when C6-01=2 (Normal Duty 2)
Table B.3 Parameter Defaults 208-240V
Parameter
208-240V: Model Number CIMR-F7U-
20P4 20P7 21P5 22P2 23P7 25P5 27P5 2011 2015
b8-03 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
b8-04 288.20 223.70 169.40 156.80 122.90 94.75 72.69 70.44 63.13
C6-01 000000000
C6-03 2, *10 2, *10 2, *10 2, *8 2, *10 2, *15 2, *15 2, *8 2, *10
E2-01 / E4-01 1.90 3.30 6.20 8.50 14.00 19.60 26.60 39.7 53.0
E2-02 / E4-02 2.90 2.50 2.60 2.90 2.73 1.50 1.30 1.70 1.60
E2-03 / E4-03 1.20 1.80 2.80 3.00 4.50 5.10 8.00 11.2 15.2
E2-05 / E4-05 9.842 5.156 1.997 1.601 0.771 0.399 0.288 0.230 0.138
E2-06 / E4-06 18.2 13.8 18.5 18.4 19.6 18.2 15.5 19.5 17.2
E2-10 14265377112172262245272
E2-11 / E4-07 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15
L2-02 0.1 0.2 0.3 0.5 1.0 1.0 1.0 2.0 2.0
L2-03 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9
L2-04 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.6
L8-02 95 95 95 100 95 95 95 95 90
o2-04 012345678
Table B.3 Parameter Defaults 208-240V (continued)
Parameter
208-240V: Model Number CIMR-F7U-
2018 2022 2030 2037 2045 2055 2075 2090 2110
b8-03 0.50 0.50 0.50 0.50 0.50 2.00 2.00 2.00 2.00
b8-04 57.87 51.79 46.27 38.16 35.78 31.35 23.10 20.65 18.12
C6-01 000000001
C6-03 2, *10 2, *10 2, *10 2, *5 2, *5 2, *8 2, *2 2, *2 2, *2
E2-01 / E4-01 65.8 77.2 105.0 131.0 160.0 190.0 260.0 260.0 260.0
E2-02 / E4-021.671.701.801.331.601.431.391.391.39
E2-03 / E4-03 15.7 18.5 21.9 38.2 44.0 45.6 72.0 72.0 72.0
E2-05 / E4-05 0.101 0.079 0.064 0.039 0.030 0.022 0.023 0.023 0.023
E2-06 / E4-06 20.1 19.5 20.8 18.8 20.2 20.5 20.0 20.0 20.0
E2-10 505 538 699 823 852 960 1200 1200 1200
E2-11 / E4-0718.522303745557590110
L2-02 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
L2-03 1.0 1.0 1.1 1.1 1.2 1.2 1.3 1.5 1.7
L2-04 0.6 0.6 0.6 0.6 0.6 1.0 1.0 1.0 1.0
L8-02 100 90 90 95 100 105 110 100 95
o2-04 9 A B C D E F 10 11
