Capacity Related Parameters B - 5
* Default and maximum carrier frequency value when C6-01=2 (Normal Duty 2)
* Default and maximum carrier frequency value when C6-01=2 (Normal Duty 2)
Table B.4 Parameter Defaults 480V
Parameter
Model Number CIMR-F7U-
40P4 40P7 41P5 42P2 43P7 44P0 45P5 47P5 4011
b8-03 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
b8-04 576.40 447.40 338.80 313.60 245.80 236.44 189.50 145.38 140.88
C6-01 000000000
C6-03 2, *2 2, *2 2, *15 2, *15 2, *15 2, *15 2, *15 2, *15 2, *8
E2-01 / E4-011.001.603.104.207.007.009.8013.3019.9
E2-02 / E4-022.902.602.503.002.702.701.501.301.70
E2-03 / E4-030.600.801.401.502.302.302.604.00 5.6
E2-05 / E4-05 38.198 22.459 10.100 6.495 3.333 3.333 1.595 1.152 0.922
E2-06 / E4-06 18.2 14.3 18.3 18.7 19.3 19.3 18.2 15.5 19.6
E2-10 14 26 53 77 130 130 193 263 385
E2-11 / E4-07 0.4 0.75 1.5 2.2 3.7 4.0 5.5 7.5 11
L2-02 0.1 0.1 0.2 0.3 0.5 0.5 0.8 0.8 1.0
L2-03 0.1 0.2 0.3 0.4 0.5 0.6 0.6 0.7 0.8
L2-04 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L8-02 959595959595959595
o2-04 20 21 22 23 24 25 26 27 28
Table B.4 Parameter Defaults 480V (continued)
Parameter
Model Number CIMR-F7U-
4015 4018 4022 4030 4037 4045 4055 4075 4090
b8-03 0.50 0.50 0.50 0.50 0.50 0.50 2.00 2.00 2.00
b8-04 126.26 115.74 103.58 92.54 76.32 71.56 67.20 46.20 38.91
C6-01 000000000
C6-03 2, *10 2, *10 2, *10 2, *8 2, *8 2, *8 2, *5 2, *5 2, *8
E2-01 / E4-01 26.5 32.9 38.6 52.3 65.6 79.7 95.0 130.0 156.0
E2-02 / E4-021.601.671.701.801.331.601.461.391.40
E2-03 / E4-03 7.6 7.8 9.2 10.9 19.1 22.0 24.0 36.0 40.0
E2-05 / E4-05 0.550 0.403 0.316 0.269 0.155 0.122 0.088 0.092 0.056
E2-06 / E4-06 17.2 20.1 23.5 20.7 18.8 19.9 20.0 20.0 20.0
E2-10 440 508 586 750 925 1125 1260 1600 1760
E2-11 / E4-071518.522303745557590
L2-02 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
L2-03 0.9 1.0 1.0 1.1 1.1 1.2 1.2 1.3 1.5
L2-04 0.3 0.6 0.6 0.6 0.6 0.6 1.0 1.0 1.0
L8-02 9598788585909098108
o2-04 29 2A 2B 2C 2D 2E 2F 30 31
