YASKAWA F7 User Manual

Capacity Related Parameters B - 6
* Default and maximum carrier frequency value when C6-01=2 (Normal Duty 2)
Table B.4 Parameter Defaults 480V (continued)
Parameter
Model Number CIMR-F7U-
4110 4132 4160 4185 4220 4300
b8-03 2.00 2.00 2.00 2.00 2.00 2.00
b8-04 36.23 32.79 30.13 30.57 27.13 21.76
C6-01 000011
C6-03 2, *5 2, *5 2, *5 2, *2 2, *2 2, *2
E2-01 / E4-01 190.0 223.0 270.0 310.0 370.0 500.0
E2-02 / E4-021.401.381.351.301.301.25
E2-03 / E4-03 49.0 58.0 70.0 81.0 96.0 130.0
E2-05 / E4-05 0.046 0.035 0.029 0.025 0.020 0.014
E2-06 / E4-06 20.0 20.0 20.0 20.0 20.0 20.0
E2-10 2150 2350 2850 3200 3700 4700
E2-11 / E4-07 110 132 160 185 220 300
L2-02 2.0 2.0 2.0 2.0 2.0 2.1
L2-03 1.7 1.7 1.8 1.9 2.0 2.1
L2-04 1.0 1.0 1.0 1.0 1.0 1.0
L8-02 100 110 108 95 100 95
o2-04 32 33 34 35 36 37
