Peripheral Devices E - 3
Table E.2 Recommended Fuse and Circuit Breaker Ratings per NEC (480Vac Input)
Model
CIMR-F7U
Hp
Input
Amps
*1
(Continuous
Rating)
Output
Amps
*1
(Continuous
Rating)
Fuse
Selection Criteria
Circuit Breaker
Selection Criteria
Maximum
Time-Delay
Fuse Rating (A)
Maximum
Non-Time-Delay
Fuse Rating (A)
Maximum CB
Rating (A)
40P4 0.5/0.75 2.2 1.8 4 10 15
40P7 1 2.5 2.1 4 10 15
41P5 1.5/2 4.4 3.7 8 12 15
42P2 3 6.4 5.3 10 15 15
43P7 5 9 7.6 15 20 20
44P0 - 10.4 8.7 15 30 20
45P5 7.5 15 12.5 25 30 30
47P5 10 20 17 30 30 40
4011 15/20 33 27 45 50 60
4015 25 40 34 60 70 80
4018 30 48 40 70 80 90
4022 - 55 50.4 80 80 100
4030 40/50 74 67.2 100 100 125
4037 60 85 77 125 125 150
4045 75 106 96 150 150 200
4055 100 134 125 200 200 225
4075 125 172 156 250 250 300
4090 150 198 180 300 300 400
4110 200 264 240 350 350 450
4132 - 286 260 400 400 600
4160 250 334 304 450 450 700
4185 300/350 456 414 600 600 800
4220 400/450 567 515 700 700 1000
4300 500+ 743 675 900 900 1200
*1 Input and Output Amps are based on the Normal Duty (ND) current rating. Consult the Specification section for details on the Heavy Duty (HD) and Normal Duty (ND) ratings.
