YASKAWA F7 User Manual

Peripheral Devices E - 4
Table E.3 Semiconductor Fuses for Drive I
2
t Protection and Branch Circuit Short Circuit Protection (200V Series)
Drive
Model No.
CIMR-F7*
Recommended Alternate 1 Alternate 2
Fuse
Mfr.
Model No. Rating Fuse Mfr. Model No. Rating Fuse Mfr. Model No. Rating
20P4 Ferraz A60Q12-2 600V, 12A Ferraz A070GRB006T13 700V, 6A Bussmann FWH-20A14F 500V, 20A
20P7 Ferraz A60Q12-2 600V, 12A Ferraz A070GRB006T13 700V, 6A Bussmann FWH-20A14F 500V, 20A
21P5 Ferraz A60Q15-2 600V, 15A Ferraz A70QS25-22F 700A, 25A Bussmann FWH-20A14F 500V, 20A
22P2 Ferraz A60Q20-2 600V, 20A Ferraz 6,900CPGRC14.51/25 690V, 25A Bussmann FWH-25A14F 500V, 25A
23P7 Ferraz A60Q30-2 600V, 30A Ferraz A70QS32-14F 700A, 32A Bussmann FWH-45B 500V, 45A
25P5 Ferraz A50P50-4 500V, 50A Ferraz A70QS50-14F 700V, 50A Bussmann FWH-80B 500V, 80A
27P5 Ferraz A50P80-4 500V, 80A Ferraz A50QS70-4 500V, 70A Bussmann FWH-80B 500V, 80A
2011 Ferraz A50P80-4 500V, 80A Ferraz A50QS100-4 500V, 100A Bussmann FWH-100B 500V, 100A
2015 Ferraz A50P125-4 500V, 125A Ferraz A50QS150-4 500V, 150A Bussmann FWH-175B 500V, 175A
2018 Ferraz A50P150-4 500V, 150A Ferraz A50QS175-4 500V, 175A Bussmann FWH-200B 500V, 200A
2022 Ferraz A50P150-4 500V, 150A Ferraz A50QS200-4 500V, 200A Bussmann FWH-200B 500V, 200A
2030 Ferraz A50P200-4 500V, 200A Bussmann FWH-200B 500V, 200A Bussmann FWH-225B 500V, 225A
2037 Ferraz A50P250-4 500V, 250A Ferraz A30QS275-4 300V, 275A Bussmann 170M4610 690V, 315A
2045 Ferraz A50P300-4 500V, 300A Ferraz A30QS350-4 300V, 350A Bussmann FWH-350A 500V, 350A
2055 Ferraz A50P350-4 500V, 350A Bussmann FWH-400A 500V, 400A Bussmann FWH-450A 500V, 450A
2075 Ferraz A50P450-4 500V, 450A Ferraz A070URD33KI0550 700V, 550A Bussmann FWH-500A 500V, 500A
2090 Ferraz A50P600-4 500V, 600A Ferraz A70P600-4 700V, 600A Bussmann FWH-600A 500V, 600A
2110 Ferraz A50P600-4 500V, 600A Ferraz A70P700-4 700V, 700A Bussmann FWH-700A 500V, 700A
* Denotes letter A through Z
