YASKAWA FP65U T Series User Manual

12 UL Standards
YASKAWA TOEPC7106171FD FP605 DRIVE INSTALLATION & PRIMARY OPERATION 81
Required Short Circuit Protection
Table 12.2 Required Short Circuit Protection for FP605 AC Drives (240 V Class)
Drive
Catalog
Code
FP65U
Drive Mounted without
Supplemental Enclosure
(Using Type 1 Kit)
Drive Mounted in Supplemental Enclosure
Any Size Protected Enclosure
(Ventilated or Non-Ventilated)
Restricted Size Protected Enclosure
(Ventilated Only)
Semiconductor
Fuse
*1
Part Number
(Permitted Only
in Type 1 Kit)
Manufacturer:
Eaton/Bussmann
Class CC, J, or T
Fuse
*2
Maximum Amps
Semiconductor
Fuse
*1
Part Number
Manufacturer:
Eaton/Bussmann
Class CC, J, or T
Fuse
*2 *3
Maximum Amps
Class CC, J, or T
Fuse
*2 *3
Maximum Amps
MCCB
*3
Maximum
Amps
MCP
*1
Part Number
Manufacturer:
Schneider
Enclosure Volume
Minimum (in
3
)
External
Heatsink
Internal
Heatsink
2011
Not allowed.
Does not support
internal fuses for
these drive models.
17.5 FWH‐40B 17.5
Enclosure volume
not restricted.
Refer to the values
in the column to the
left for fuses.
25 HLL36030M71 3056 3056
2017 25 FWH‐45B 25 40 HLL36030M71 3056 3056
2024 40 FWH‐80B 40 60 HLL36050M72 3056 3056
2031 50 FWH‐125B 50 75 HLL36050M72 3056 3056
2046 80 FWH‐125B 80 110 HLL36100M73 5520 5520
2059 100 FWH‐175B 100 125 HLL36100M73 5520 5520
2075 125 FWH‐200B 125 175 HLL36150M74 5520 5520
2088 150 FWH‐225A 150 200 HLL36150M74 5520 5520
2114 200 FWH‐225A 200 250 HLL36150M74 5520 5520
2143 250 FWH‐250A 250 350 JLL36250M75 21582 14657
2169 250 FWH‐275A 250 400 JLL36250M75 21582 14657
2211 350 FWH‐600A 350 500
LAL3640036M
or
LLL36400M37X
52800 14657
2273 450 FWH‐800A 450 600
LAL3640036M
or
LLL36400M37X
52800 14657
2343 600
FWH-1000A
or
FWH-1000B
600 700 PLL34060M68 52800 52800
2396 700
FWH-1000A
or
FWH-1000B
700 800 PLL34060M68 52800 52800
*1 Protection device must be in same enclosure with drive.
*2 Class T fuses are fast-acting (non‐time-delay) only. Class CC and J can be either time-delay or non-time-delay.
*3 Protection device and drive permitted in same or separate enclosure.
