2 Mechanical Installation
22 YASK AWA TOEPYAIL1E01A YASKAWA AC Drive L1000E Quick Start Guide
IP00 Enclosure Drive
Table 5 Dimensions: 200 V Class
Table 6 Dimensions: 400 V Class
Drive Model Figure
Dimensions mm (in) Weight
kg
(lbs)
W H D W1 H1 H2 D1 t1 t2 d
2A0269
1
450
(17.70)
706
(27.80)
330
(13.00)
325
(12.80)
681
(26.80)
13
(0.50)
130
(5.10)
3
(0.10)
3
(0.10)
M10
76
(167.6)
2A0354
450
(17.70)
706
(27.80)
330
(13.00)
325
(12.80)
681
(26.80)
13
(0.50)
130
(5.10)
3
(0.10)
3
(0.10)
M10
80
(176.4)
2A0432
500
(19.70)
800
(31.50)
330
(13.00)
371
(14.60)
772
(30.40)
13
(0.50)
130
(5.10)
5
(0.20)
5
(0.20)
M12
98
(216.1)
Drive Model Figure
Dimensions mm (in) Weight
kg
(lbs)
W H D W1 H1 H2 D1 t1 t2 d
4A0225
1
450
(17.70)
706
(27.80)
330
(13.00)
325
(12.80)
681
(26.80)
13
(0.50)
130
(5.10)
3
(0.10)
3
(0.10)
M10
79
(174.2)
4A0260
500
(19.70)
800
(31.50)
330
(13.00)
371
(14.60)
772
(30.40)
13
(0.50)
130
(5.10)
5
(0.20)
5
(0.20)
M12
96
(211.6)
4-d
W
t1
D
H1
H
W1
H2
t2
D1
Figure 1
PWRLED MONITOR JVOP-184
RUN DS1 DS2
RUN DS1 DS2 STATUS
READY
RUN
ALARM(RUN)
PGOH,LT
BB,HBB
EF,SE
Other Fault
OV,UV
OH,OL
OC,GF,SC,PGO
CPF,OFA,OFB,OFC
:LIGHT :BLINK :LIGHT OFF
Max 8
(0.31)
Max 8
(0.31)
