YASKAWA L1000E - Page 35

3 Electrical Installation
YASK AWA TOEPYAIL1E01A YASKAWA AC Drive L1000E Quick Start Guide 35
Electrical Installation
3
2A0075
R/L1, S/L2, T/L3
35
(3)
6.0 to 35
(10 to 2)
M8
9 to11
(79.7 to 97.4)
U/T1, V/T2, W/T3
35
(3)
6.0 to 35
(10 to 2)
–, +1, +2 –
16 to 25
(4 to 3)
B1, B2 –
10 to 16
(8 to 6)
M5
2 to 2.5
(17.7 to 22.1)
16
(6)
16 to 25
(6 to 4)
M6
4 to 6
(35.4 to 53.1)
2A0094
R/L1, S/L2, T/L3
35
(2)
6.0 to 35
(10 to 2)
M8
9 to11
(79.7 to 97.4)
U/T1, V/T2, W/T3
16 × 2P
(6 × 2P)
6.0 to 35
(10 to 2)
–, +1, +2 – 25 to 35
(3 to 2)
B1, B2 –
16
(6)
M5
2 to 2.5
(17.7 to 22.1)
16
(6)
16 to 25
(6 to 4)
M6
4 to 6
(35.4 to 53.1)
2A0106
R/L1, S/L2, T/L3
70
(1/0)
6.0 to 50
(10 to 1/0)
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2, W/T3
70
(1/0)
6.0 to 50
(10 to 1/0)
–, +1 –
35 to 50
(2 to 1/0)
B1, B2 –
16 to 50
(6 to 1/0)
16
(6)
16 to 25
(6 to 4)
2A0144
R/L1, S/L2, T/L3
70
(2/0)
6.0 to 95
(10 to 3/0)
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3
95
(3/0)
6.0 to 95
(10 to 3/0)
–, +1 –
50 to 70
(1/0 to 3/0)
B1, B2 –
25 to 70
(4 to 2/0)
25
(4)
25
(4)
M8
9 to 11
(79.7 to 97.4)
2A0181
R/L1, S/L2, T/L3
95
(4/0)
70 to 95
(1/0 to 4/0)
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3
95
(4/0)
70 to 95
(1/0 to 4/0)
–, +1 –
50 to 95
(1 to 4/0)
+3 –
70 to 95
(1/0 to 4/0)
25
(4)
25 to 35
(4 to 2)
Drive Model Terminal
Recommended
Wire Size
mm
2
(AWG, kcmil)
Wire Range
mm
2
(AWG, kcmil)
Screw
Size
Tightening Torque
N•m (lb.in.)
