Note: When connecting peripheral devices and options to the terminals –, +1, +3, B1, and B2, refer to the instruction manuals for each
device. For more information, contact Yaskawa or your nearest sales representative.
4A0114
R/L1, S/L2, T/L3
70
(1/0)
16 to 120
(6 to 250)
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2, W/T3
70
(1/0)
16 to 120
(6 to 250)
–, +1 –
25 to 50
(3 to 1/0)
+3 –
25 to 50
(4 to 1/0)
25
(4)
16 to 25
(6 to 4)
4A0140
R/L1, S/L2, T/L3
95
(3/0)
50 to 95
(1/0 to 4/0)
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3
70
(2/0)
50 to 95
(1/0 to 4/0)
–, +1 –
50 to 95
(1/0 to 4/0)
+3 –
25 to 95
(3 to 4/0)
25
(4)
25
(4)
4A0188
R/L1, S/L2, T/L3
95
(4/0)
50 to 95
(1/0 to 4/0)
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3
95
(4/0)
50 to 95
(1/0 to 4/0)
–, +1 –
35 to 95
(1 to 4/0)
+3 –
50 to 95
(1/0 to 4/0)
25
(4)
25 to 35
(4 to 2)
4A0225
R/L1, S/L2, T/L3
50 × 2P
(1 × 2P)
35 to 150
(2 to 300)
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3
70 × 2P
(1/0 × 2P)
35 to 150
(2 to 300)
–, +1 –
50 to 150
(1 to 250)
+3 –
25 to 70
(3 to 3/0)
25
(4)
25 to 150
(4 to 300)
4A0260
R/L1, S/L2, T/L3
70 × 2P
(2/0 × 2P)
95 to 300
(1 to 600)
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3
70 × 2P
(2/0 × 2P)
95 to 300
(1/0 to 600)
–, +1 –
70 to 300
(3/0 to 600)
+3 –
35 to 185
(1 to 325)
35
(2)
35 to 185
(2 to 350)
Drive Model Terminal
Recommended
Wire Size
mm
2
(AWG, kcmil)
Wire Range
mm
2
(AWG, kcmil)
Screw
Size
Tightening Torque
N•m (lb.in.)
