6 Related Drive Parameters
YASKAWA ELECTRIC SIEP C730600 70B V1000 Option SI-EP3/V Technical Manual 29
F7-27
(3FF)
<10>
Dynamic Output Assembly
Parameter 5
Sets configurable output 5.
Default: 0H
Min.: 0H
Max.: FFFFH
F7-33
(405)
<10>
Dynamic Input Assembly
Parameter 1
Sets configurable input 1.
Default: 0H
Min.: 0H
Max.: FFFFH
F7-34
(406)
<10>
Dynamic Input Assembly
Parameter 2
Sets configurable input 2.
Default: 0H
Min.: 0H
Max.: FFFFH
F7-35
(407)
<10>
Dynamic Input Assembly
Parameter 3
Sets configurable input 3.
Default: 0H
Min.: 0H
Max.: FFFFH
F7-36
(408)
<10>
Dynamic Input Assembly
Parameter 4
Sets configurable input 4.
Default: 0H
Min.: 0H
Max.: FFFFH
F7-37
(409)
<10>
Dynamic Input Assembly
Parameter 5
Sets configurable input 5.
Default: 0H
Min.: 0H
Max.: FFFFH
H5-11
(43C)
Communications ENTER Function
Selection
Selects whether an Enter command is necessary to change parameter
values via MEMOBUS/Modbus communications.
0: Parameter changes are activated when ENTER command is written
1: Parameter changes are activated immediately without use of ENTER
command
Default: 1
Range: 0, 1
<1> Set b1-02 = 3 to start and stop the drive with the PROFINET master device using serial communications.
Set b1-01 = 3 to control the frequency reference of the drive via the master device.
<2> Setting this parameter to 3 will cause the drive to continue operation after detecting a fault. Take proper measures such as installing an
emergency stop switch when using setting 3.
<3> Available in the V1000 software versions PRG: 1024 and later. Refer to the instruction manual of a specific drive to determine if settings 4 and
5 are available in the drive.
<4> Cycle power for setting changes to take effect.
<5> If F7-13 is set to 0, then all IP Addresses (F7-01 to F7-04) must be unique.
<6> Set F7-01 to F7-12 when F7-13 is set to 0.
<7> Default setting differs by drive software version.
1012 to 1015: 0
≥1016: 1
<8> Set F7-15 when F7-14 is set to 0 or 2.
<9> The setting values differ by drive software version.
1012 to 1015
Default: 0
Range: 0, 10, 100
≥1016
Default: 10
Range: 10, 100
<10> If a value other than 0 is assigned to parameters F7-23 to F7-27 and F7-33 to F7-37 by the drive, that value will take precedent over a value set
by the configuration software. If the value in the drive is 0 (default), the value from the configuration software is used.
No.
(Addr.
Hex)
Name Description Values
