6 Related Drive Parameters
YASKAWA ELECTRIC SIEP C730600 70B V1000 Option SI-EP3/V Technical Manual 27
6 Related Drive Parameters
The parameters in Table 10 set the drive for operation with the option. Confirm proper setting of all parameters in
Tabl e 1 0 before starting network communications. Refer to the manual packaged with the drive for details on setting
parameters.
Table 10 Related Parameter Settings
No.
(Addr.
Hex)
Name Description Values
b1-01
(180)
<1>
Reference 1 Source
Selects the input method for frequency reference.
0: Keypad
1: Analog Input
2: Memobus/Modbus Communications
3: Option PCB
4: Pulse Train Input
Default: 1
Range: 0 to 4
(Set to 3)
b1-02
(181)
<1>
Run Command 1 Source
Selects the input method for the Run command.
0: Keypad
1: Digital Input
2: Memobus/Modbus Communications
3: Option PCB
Default: 1
Range: 0 to 3
(Set to 3)
F6-01
(3A2)
<2>
Communication Error Selection
Selects drive response when a bUS error is detected during
communications with the option.
0: Ramp to Stop
1: Coast to Stop
2: Fast Stop (Use C1-09)
3: Alarm Only
<2>
4: Alarm - Run at d1-04 <2>
5: Alarm - Ramp to Stop
Default: 1
Range: 0 to 53
F6-02
(3A3)
Comm External Fault (EF0) Detect
Selects the condition for external fault detection (EF0).
0: Always detected
1: Detection during run only
Default: 0
Range: 0, 1
F6-03
(3A4)
Comm External Fault (EF0) Select
Selects drive response for external fault input (EF0) detection during
option communications.
0: Ramp to Stop
1: Coast to Stop
2: Fast Stop (Use C1-09)
3: Alarm Only
<2>
Default: 1
Range: 0 to 3
F6-07
(3A8)
MultiStep Ref Priority Select
0: MultiStep References Disabled
1: MultiStep References Enabled
Default: 1
Range: 0, 1
F6-08
(36A)
Comm Parameter Reset
@Initialize
Selects whether communication-related parameters F6- and F7-
are set back to original default values when the drive is initialized using
parameter A1-03.
0: No Reset - Parameters retained
1: Reset - Back to factory default
Note: The setting value is not changed even when F6-08 is set to 1 and the
drive is initialized using A1-03.
Default: 0
Range: 0, 1
F6-15
(B5B)
Comm. Option Parameter Upgrade
Selection
Selects whether F6-/F7- communication-related parameters
changed are enabled.
0: Enabled by Cycling the Power
1: Enabled F6-/F7-
2: Disabled F6-/F7-
Note: F6-15 is reset to 0 after setting to 1 or 2.
Default: 0
Range: 0 to 2
F7-01
(3E5)
IP Address 1
Sets the static/fixed IP address.
Parameter F7-01 sets the most significant octet.
Default: 192
Min: 0
Max: 255
F7-02
(3E6)
IP Address 2
Sets the static/fixed IP address.
Parameter F7-02 sets the second most significant octet.
Default: 168
Min: 0
Max: 255
F7-03
(3E7)
IP Address 3
Sets the static/fixed IP address.
Parameter F7-03 sets the third most significant octet.
Default: 1
Min: 0
Max: 255
