9 Web Interface
9Web Interface
The web server interface to the drive option through port 80 allows management of diagnostic information through a
standard web browser. The web page is a Java applet that creates a tabbed web page. The available tabs include:
•Main Tab
• Drive Status Tab
•Network Tab
• Doc links Tab
• Email Alerts Tab
• Parameter Access Tab
<1>
• Configuration Tab <1>
•Custom Tab
Access the web server interface by typing the IP address of the SI-EP3/V option in a web browser address.
Example: "http://192.168.1.20"
The SI-EP3/V IP Address is available using drive digital operator to access Option Monitors U6-80 to U6-83.
Refer to Table 11 for details.
 Main Tab
The Main tab shows basic option information such as IP address, MAC address, and firmware version.
Figure 35
Figure 36 Main Tab View
Note: The initial password is yaskawa. To change the password, open the Configuration Tab.
<1> PCs must have Java SE 6 Update 14 or later installed to view the web pages. PCs without Java will display web pages with limited features.
