8 Communication
36 YASKAWA ELECTRIC SIEP C730600 70B V1000 Option SI-EP3/V Technical Manual
 Yaskawa SI-EP3/V PROFINET I/O Modules
Std Tgm 1
Table 15 Std Tgm 1 Consume
Table 16 Std Tgm 1 Produce
Std Tgm 1 + 5 PZD
Table 17 Std Tgm 1 + 5 PZD Consume
Table 18 Std Tgm 1 + 5 PZD Produce
Bytes Description
0 Control Word MSB
1Control Word LSB
2 Frequency Reference MSB
3 Frequency Reference LSB
Bytes Description
0 Status Word MSB
1 Status Word LSB
2 Output Frequency MSB
3 Output Frequency LSB
Bytes Description
0 Control Word MSB
1Control Word LSB
2 Frequency Reference MSB
3 Frequency Reference LSB
4 Configurable Output 1 MSB
5 Configurable Output 1 LSB
6 Configurable Output 2 MSB
7 Configurable Output 2 LSB
8 Configurable Output 3 MSB
9 Configurable Output 3 LSB
10 Configurable Output 4 MSB
11 Configurable Output 4 LSB
12 Configurable Output 5 MSB
13 Configurable Output 5 LSB
Bytes Description
0 Status Word MSB
1 Status Word LSB
2 Output Frequency MSB
3 Output Frequency LSB
4 Configurable Input 1 MSB
5 Configurable Input 1 LSB
6 Configurable Input 2 MSB
7 Configurable Input 2 LSB
8 Configurable Input 3 MSB
9 Configurable Input 3 LSB
10 Configurable Input 4 MSB
11 Configurable Input 4 LSB
12 Configurable Input 5 MSB
13 Configurable Input 5 LSB
