YASKAWA SGDV-180A - Fuse Sizing Chart - Yaskawa

SERVOPACK
Model
SGDV-
Rated Input
Current (A)
Recommended
Fuse Size
(A)
R70F
1.5
2
R90F
2.5
4
2R1F
5
6
2R8F
10
10
R70A
1
2
R90A
1
2
1R6A
2
4
2R8A
3
4
3R8A
3
4
5R5A
6
8
7R6A
6
8
120A
7.5
8
180A
10
10
200A
15
16
330A
25
25
470A
29
32
550A
37
Breaker
590A
54
Breaker
780A
73
Breaker
1R9D
1.4
2
3R5D
2.9
4
5R4D
4.3
6
8R4D
5.8
6
120D
8.6
10
170D
14.5
16
210D
17.4
25
260D
21.7
25
280D
31.8
32
370D
43.4
Breaker
