5 Installation Procedure
20 YASKAWA ELECTRIC TOBP C730600 89D YASKAWA AC Drive Option SI-EP3 Installation Manual
u Procedures for Installing and Wiring Options on a Drive
Procedures to install and wire the option are different for different drivel models.
Refer to Table 6 to check the procedures to install and wire the option on a drive.
Table 6 Procedures for Installing and Wiring Options on a Drive
Product Series
<1> Use the option card installation case manual to install the option on GA500 drives.
<2> Before you install the option on a YASKAWA AC Drive GA500, make sure that the option software version is
PRG: 4400 or later.
Procedures for Installing and
Wiring Options on a Drive
Page
A1000 Procedure A 21
U1000 Procedure A 21
U1000L Procedure A 21
Z1000U Procedure A 21
GA500
<1> <2> –
GA700 Procedure B 27
GA800 Procedure B 27
