Table 8 Option Monitors
No. Name Description Range
U6-80 to U6-83 OPT IP ADR 1 to 4
Displays IP Address currently available;
• U6 -80: First octet
• U6 -81: Second octet
• U6 -82: Third octet
• U6 -83: Forth octet
0 to 255
U6-84 to U6-87 Online Subnet 1 to 4
Displays subnet currently available;
• U6 -84: First octet
• U6 -85: Second octet
• U6 -86: Third octet
• U6 -87: Forth octet
0 to 255
U6-88 to U6-91 Online Gateway
Displays gateway currently available;
• U6 -88: First octet
• U6 -89: Second octet
• U6 -90: Third octet
• U6 -91: Forth octet
0 to 255
U6-92 Online Speed
Displays CN1 Port 1 link speed currently
available.
10, 100
U6-93 Online Duplex
Displays CN1 Port 1 duplex setting currently
available.
0: Half, 1: Full
U6-94 Online Speed
Displays CN1 Port 2 link speed currently
available.
10, 100
U6-95 Online Duplex
Displays CN1 Port 2 duplex setting currently
available.
0: Half, 1: Full
U6-97 OPT SPARE 4 Displays option software version. -
U6-98 First Fault
Displays first option fault. Refer to Option
Fault Monitors U6-98 and U6-99 on page 60
for details.
-
U6-99 Current Fault
Displays current option fault. Refer to Option
Fault Monitors U6-98 and U6-99 on page 60
for details.
-
