YASKAWA SI-EP3

9 Troubleshooting
YASKAWA ELECTRIC TOBP C730600 89D YASKAWA AC Drive Option SI-EP3 Installation Manual 61
u Option Compatibility
Users may connect up to 3 options simultaneously depending on the type of option.
Refer to Table 15 for details.
Note: You can only connect one option to the GA500. Connect the option card to the CN5 connector.
Table 15 Option Compatibility
Option Card
<1> When connecting two PG option cards, use both CN5-B and CN5-C. When connecting only one PG option card,
use the CN5-C connector.
<2> Not available for the application with Motor 2 Selection.
<3> Not available with 1000-Series drive models with a capacities between 450 and 630 kW.
<4> When you use the input status of AI-A3 and DI-A3 as a monitor, you can connect AI-A3 and DI-A3 to CN5-A,
CN5-B, or CN5-C.
Connector Number of Cards Possible
PG-B3, PG-X3 CN5-B, C 2
<1>
PG-RT3 <2> <3> , PG-F3 <2> <3> CN5-C 1
DO-A3, AO-A3 CN5-A, B, C 1
SI-C3, SI-N3, SI-P3, SI-S3, SI-T3,
SI-ET3, SI-ES3, SI-B3, SI-M3,
SI-W3
<3> , SI-EM3 <3> , SI-EN3 <3> ,
SI-EP3, AI-A3
<4> , DI-A3 <4> ,
SI-EN3D, SI-EM3D
CN5-A 1
