YASKAWA V1000 Series Option Manual

Mounting Hole (x4-Ma)
Attachment 1
Attachment 3
Attachment 2
W
W1
D1
D2
min. D3
H
H1
Figure 2 External Heatsink Option Outline Dimensions
Table 5 External Heatsink Option Outline Dimensions by Model (Figure 2)
Drive Model
CIMR-V
Dimensions mm (in)
W W1 H H1 D1 D2 D3 a
o2o0030
158
(6.2)
122
(4.8)
286
(11.3)
272
(10.7)
86.6
(3.4)
53.4
(2.1)
60
(2.4)
5
(0.2)
o2o0040
158
(6.2)
122
(4.8)
286
(11.3)
272
(10.7)
86.6
(3.4)
53.4
(2.1)
60
(2.4)
5
(0.2)
o2o0056
198
(7.8)
160
(6.3)
322
(12.7)
308
(12.1)
89.6
(3.4)
73.4
(2.9)
80
(3.1)
5
(0.2)
o2o0069
241
(9.5)
192
(7.5)
380
(15.0)
362
(14.2)
110.6
(4.4)
76.4
(3.0)
85
(3.3)
5
(0.2)
o4o0018
158
(6.2)
122
(4.8)
286
(11.3)
272
(10.7)
86.6
(3.4)
53.4
(2.1)
60
(2.4)
5
(0.2)
o4o0023
158
(6.2)
122
(4.8)
286
(11.3)
272
(10.7)
86.6
(3.4)
53.4
(2.1)
60
(2.4)
5
(0.2)
o4o0031
198
(7.8)
160
(6.3)
322
(12.7)
308
(12.1)
89.6
(3.5)
53.4
(2.1)
60
(2.4)
5
(0.2)
o4o0038
198
(7.8)
160
(6.3)
322
(12.7)
308
(12.1)
69.5
(2.7)
73.4
(2.9)
80
(3.1)
5
(0.2)
4 External Heatsink Option Installation Procedure
YASKAWA V1000/J1000 AC Drive External Heatsink Kit Option Manual EZZ020568
11

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
