YASKAWA V1000 Series Option Manual

5 Installation Procedure by Drive Model
Table 6 External Heatsink Option Installation Procedure by Model
Drive Model
CIMR-V or J
Installation Procedure Page Figure
oBo0001
oBo0002
1 13 Figure 3
oBo0003
oBo0006
3 15 Figure 5
oBo0010
oBo0012
3, 4 15, 15
Figure 5
Figure 6
oBo0018
3 15 Figure 5
o2o0001
o2o0002
1 13 Figure 3
o2o0004
o2o0006
o2o0008
o2o0010
3, 4 15, 15
Figure 5
Figure 6
o2o0012
o2o0018
o2o0020
o4o0001
2 14 Figure 4
o4o0002
3 15 Figure 5
o4o0004
o4o0005
o4o0007
o4o0009
3, 4 15, 15
Figure 5
Figure 6
o4o0011
o2o0030
5 18 Figure 8
o2o0040
o2o0056
o2o0069
o4o0018
o4o0023
o4o0031
o4o0038
5 Installation Procedure by Drive Model
12
YASKAWA V1000/J1000 AC Drive External Heatsink Kit Option Manual EZZ020568

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
