YASKAWA V1000 Series Option Manual

4 External Heatsink Option Installation Procedure
u
Drive Dimensions with External Heatsink Option Installed
This section provides figures and tables of drive dimensions with the External Heatsink Option installed.
Table 3 Drive Models and Dimensions
Series Drive Model Number Reference
J1000
CIMR-JoBo0001 to 0010
Figure 1
CIMR-Jo2o0001 to 0020
CIMR-Jo4o0001 to 0011
V1000
CIMR-VoBo0001 to 0018
CIMR-Vo2o0001 to 0020
CIMR-Vo4o0001 to 0011
CIMR-Vo2o0030 to 0069
Figure 2
CIMR-Vo4o0018 to 0038
4 External Heatsink Option Installation Procedure
YASKAWA V1000/J1000 AC Drive External Heatsink Kit Option Manual EZZ020568
9

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
