■ Heavy Duty
Table 7 Drive Watt Loss (Heavy Duty Rating)
200 V Single-PhaseClass
Model
CIMR-VBA
<1> Carrier frequency is set to 10 kHZ.
<2> Carrier frequency is set to 8 kHZ.
0001
<1>
0002
<1>
0003
<1>
0006
<1>
–
0010
<2>
0012
<2>
––––––
Rated Output Current
(A)
0.8 1.6 3.0 5.0 – 8.0 11.0 – – – – – –
Generated
Heat Loss
Heatsink
Plate (W)
4.3 7.9 16.1 33.7 – 54.8 70.7 – – – – – –
Internal (W) 7.4 8.9 11.5 16.8 – 25.9 34.1 – – – – – –
Total (W) 11.7 16.8 27.6 50.5 – 80.7 104.8 – – – – – –
200 V Three-Phase Class
Model
CIMR-V2A
0001
<1>
0002
<1>
0004
<1>
0006
<1>
0008
<1>
0010
<2>
0012
<2>
0018
<2>
0020
<2>
0030
<2>
0040
<2>
0056
<2>
0069
<2>
Rated Output Current
(A)
0.8 1.6 3.0 5.0 6.9 8.0 11.0 14.0 17.5 25.0 33.0 47.0 60.0
Generated
Heat Loss
Heatsink
Plate (W)
4.3 7.9 16.1 27.4 48.7 54.8 70.7 92.6 110.5 213.3 239.5 347.6 473.9
Internal (W) 7.3 8.8 11.5 15.9 22.2 23.8 30.0 38.8 43.3 68.1 79.6 113.8 156.7
Total (W) 11.6 16.7 27.6 43.3 70.9 78.6 100.7 131.4 153.8 281.4 319.1 461.4 630.6
400 V Three-Phase Class
Model
CIMR-V4A
0001
<2>
0002
<2>
0004
<2>
0005
<2>
–
0007
<2>
0009
<2>
–
0011
<2>
0018
<2>
0023
<2>
0031
<2>
0038
<2>
Rated Output Current
(A)
1.2 1.8 3.4 4.8 – 5.5 7.2 – 9.2 14.8 18.0 24.0 31.0
Generated
Heat Loss
Heatsink
Plate (W)
19.2 28.9 42.3 70.7 – 81.0 84.6 – 107.2 166.0 207.1 266.9 319.1
Internal (W) 11.4 14.9 17.9 26.2 – 30.7 32.9 – 41.5 61.7 75.0 102.1 115.4
Total (W) 30.6 43.8 60.2 96.9 – 111.7 117.5 – 148.7 227.7 282.1 369.0 434.5
