12
1 RECEIVING
CAUTION
D
Do not install or operate any power regenerative unit which is damaged or
has missing parts.
Failure to observe this caution may result in personal injury or equipment
damage.
This chapter describes how to verify the VS-656RC5 after delivery to the user.
1.1 INSPECTION CHECKPOINTS
(1) Receiving Checkpoints
Table
1
Checkpoints
Checkpoints Description
Does the power regenerative unit model number
correspond with the purchase order?
Check the model number on the nameplate on the side of the
VS-656RC5. (Refer to page 13.)
Are any parts damaged?
Visually check the exterior and verify that there was no damage during
transport.
Is hardware properly seated and securely tightened?
Remove the front cover of the power regenerative unit.
Check all visible hardware with appropriate tools.
If any of the above checkpoints are not satisfactory, contact your YASKAWA
representative.
(2) Checking the Nameplate Data
(a) Nameplate Data
Example of standard domestic model CIMR-R5U23P7
YASKAWA ELECTRIC CORPORATION JAPAN
MODEL
:
CIMR-R5U23P7
M
S
INPUT
:
AC 3PH 200 - 220V 50HZ
200 - 230V 60HZ
LOT NO
:
MASS : 4.5 kg
Power Regenerative
Unit Model
Input Spec.
Output Spec.
LOT No.
Mass
10 A 1 min
25%ED
OUTPUT
:
DC 300 - 340V 13 A 1 min 25%ED
SPEC
:
23P71A
Serial No.
SER NO.
Fig.1 Nameplate Data
To Next Page
