3.2 CONNECTING MAIN AND CONTROL CIRCUITS
(1) Main Circuit Input Fuse
Connet a fuse at the primary side of the power suppressing reactor. Recom-
mended fuses are shown in Tables 3 and 4.
Table 3 200 V Class Input Fuse
VS-656RC5
Input fuse Fuse holder
Model
CIMR-R5Uj
Rated re-
generative
capacity
(kW)
25%ED
Rated
input
current
(Aac)
25%ED
Model Code No.
Amount per
unit
Model Code No.
Amount per
unit
23P7 3.7 10 CR2LS-20/UL FU000799 3 CM-1A FU002014 1
25P5 5.5 15 CR2LS-30/UL FU000791 3 CM-1A FU002014 1
27P5 7.5 20 CR2LS-30/UL FU000791 3 CM-1A FU002014 1
2011 11 30 CR2LS-50/UL FU000797 3 CM-1A FU002014 1
2015 15 40 CR2LS-75/UL FU000792 3 CM-1A FU002014 1
2018 18 50 CR2LS-100/UL FU002085 3 CM-1A FU002014 1
2022 22 60 CR2LS-100/UL FU002085 3 CM-1A FU002014 1
2030 30 80 CR2LS-150/UL FU002086 3 CM-2A FU002090 1
2037 37 100 CR2LS-150/UL FU002086 3 CM-2A FU002090 1
Note: These fuses and fuse holders are made by FUJI ELECTRIC CO., LTD.
Table 4 400 V Class Input Fuse
VS-656RC5 Input fuse Fuse holder
Model
CIMR-R5Uj
Rated re-
generative
capacity
(kW)
25%ED
Rated
input
current
(Aac)
25%ED
Model Code No.
Amount per
unit
Model Code No.
Amount per
unit
43P7 3.7 5 CR6L-20/UL FU002087 3 CMS-4 FU002091 3
45P5 5.5 7.5 CR6L-20/UL FU002087 3 CMS-4 FU002091 3
47P5 7.5 10 CR6L-20/UL FU002087 3 CMS-4 FU002091 3
4011 11 15 CR6L-30/UL FU002088 3 CMS-4 FU002091 3
4015 15 20 CR6L-30/UL FU002088 3 CMS-4 FU002091 3
4018 18 25 CR6L-50/UL FU000935 3 CMS-4 FU002091 3
4022 22 30 CR6L-50/UL FU000935 3 CMS-4 FU002091 3
4030 30 40 CR6L-75/UL FU002089 3 CMS-5 FU002092 3
4037 37 50 CR6L-75/UL FU002089 3 CMS-5 FU002092 3
4045 45 60 CR6L-100/UL FU000927 3 CMS-5 FU002092 3
4055 55 75 CR6L-150/UL FU000928 3 CMS-5 FU002092 3
4075 75 100 CR6L-150/UL FU000928 3 CMS-5 FU002092 3
Note: These fuses and fuse holders are made by FUJI ELECTRIC CO., LTD.
