2 INSTALLATION
19
2.4 REMOVING AND REPLACING THE FRONT COVER
To remove the front cover, first move the LED monitor/digital operator in the
direction shown by arrow 1. Then squeeze the cover in the direction shown by arrows
2 on both sides and lift in the direction shown by arrow 3.
Front Cover
1
2
3
2
Fig.5 Removing and Replacing the Front Cover
Do not replace the front cover with the LED monitor/digital operator
connected. The LED monitor/digital operator will not be connected to the
power regenerative unit. Replace the front cover first and then install the LED
monitor/digital operator on the cover. See Par. 2.5 for replacing the LED
monitor/digital operator.
NOTE
