(2) Input AC Reactor
An input 3-phase reactor corresponding to each model is necessary when operat-
ing VS-656RC5. This input AC reactor is effective against saturated current and
excessive heat.
Table 5 shows the code numbers of AC reactor of each model. Check the table
and use a specified AC reactor.
Table 5 AC Reactor
VS-656RC5 Power coordinating reactor Power Suppressing Reactor
Model CIMR-R5Uj Rated
current
(Arms)
Inductance
(mH)
Code No. Rated
current
(Arms)
Inductance
(mH)
Code No.
23P7 20 0.53 X002491 15 0.31 X010121
25P5 30 0.35 X002492 15 0.31 X010121
27P5 40 0.265 X002493 20 0.15 X010122
200
V
2011 60 0.18 X002495 40 0.1 X010123
200 V
Class
2015 80 0.13 X002497 40 0.1 X010123
Cl
ass
2018 90 0.12 X002498 50 0.06 X010124
2022 120 0.09 X002555 60 0.05 X010125
2030 160 0.07 X002556 80 0.04 X010126
2037 200 0.05 X002557 100 0.03 X010127
43P7 10 2.2 X002500 7.5 1.2 X010128
45P5 15 1.42 X002501 7.5 1.2 X010128
47P5 20 1.06 X002502 10 0.6 X010129
4011 30 0.7 X002503 15 0.4 X010130
4015 40 0.53 X002504 25 0.3 X010131
400 V
4018 50 0.42 X002505 25 0.3 X010131
400
V
Class
4022 60 0.36 X002506 30 0.2 X010132
4030 80 0.26 X002508 40 0.15 X010133
4037 90 0.24 X002509 50 0.12 X010134
4045 120 0.18 X002566 60 0.1 X010135
4055 150 0.15 X002567 75 0.08 X010136
4075 200 0.11 X002568 100 0.06 X010137
3 WIRING
25
