YASKAWA VARISPEED-656RC5 - Page 26

Table 6 200 V Class Surge Protector
VS-656RC5 Surge protector
Model
CIMR-R5Uj
Rated
Capacity
(kW)
25%ED
Rated
Input
Current
(Aac)
25%ED
Model
Manufactured
by
Code No.
Amount
per unit
23P7 3.7 10 R A V-781BYZ-2 Okaya Electric XX 000221 1
25P5 5.5 15 R A V-781BYZ-2 Okaya Electric XX 000221 1
27P5 7.5 20 R A V-781BYZ-2 Okaya Electric XX 000221 1
2011 11 30 R A V-781BYZ-2 Okaya Electric XX 000221 1
2015 15 40 R A V-781BYZ-2 Okaya Electric XX 000221 1
2018 18 50 R A V-781BYZ-2 Okaya Electric XX 000221 1
2022 22 60 R A V-781BYZ-2 Okaya Electric XX 000221 1
2030 30 80 R A V-781BYZ-2 Okaya Electric XX 000221 1
2037 37 100 R A V-781BYZ-2 Okaya Electric XX 000221 1
Table 7 400 V Class Surge Protector
VS-656RC5 Surge protector
Model
CIMR-R5Uj
Rated
Capacity
(kW)
25%ED
Rated
Input
Current
(Aac)
25%ED
Model
Manufactured
by
Code No.
Amount
per unit
43P7 3.7 5 R A V-152BYZ-2A Okaya Electric XX 000222 1
45P5 5.5 7.5 R A V-152BYZ-2A Okaya Electric XX 000222 1
47P5 7.5 10 R A V-152BYZ-2A Okaya Electric XX 000222 1
4011 11 15 R A V-152BYZ-2A Okaya Electric XX 000222 1
4015 15 20 R A V-152BYZ-2A Okaya Electric XX 000222 1
4018 18 25 R A V-152BYZ-2A Okaya Electric XX 000222 1
4022 22 30 R A V-152BYZ-2A Okaya Electric XX 000222 1
4030 30 40 R A V-152BYZ-2A Okaya Electric XX 000222 1
4037 37 50 R A V-152BYZ-2A Okaya Electric XX 000222 1
4045 45 60 R A V-152BYZ-2A Okaya Electric XX 000222 1
4055 55 75 R A V-152BYZ-2A Okaya Electric XX 000222 1
4075 75 100 R A V-152BYZ-2A Okaya Electric XX 000222 1
3 WIRING
27
