(2) LED Display when the Power is ON
The following shows the LED display pattern during normal operation.
RUN DS1 DS2 POWER
[At normal operation] Indicates READY
The LED display pattern is different when a fault (minor fault) occurs. Below
shows an example of LED display when a minor fault occurs. Refer to Chapter
6 and take appropriate countermeasures.
RUN DS1 DS2 POWER
[At fault (monitor fault)] Indicates a minor fault
: ON : Blinking : OFF
37
4 OPERATION
