Yealink SIP-T33P Administrator's Guide

Advanced Features
440
LED Status
Icons
Description
T48U/T48S/T48G T46U/T46S/T46G/T29G T57W/T54W/T33P/T33G
Solid green The monitored line is idle.
Fast-flashing
red
(Flashing)
(Flashing on T57W)
The monitored line is
ringing.
(Flashing)
(Flashing on T57W)
The monitored line is dial-
ing.
Solid red
The monitored line is busy
or in a call.
Slowly-flash-
ing red
The monitored line places a
call on hold.
A call is parked to the mon-
itored line.
Off
The monitored line fails to
register or does not exist.
BLF/BLF List Subscription
Yealink phones support BLF using a SUBSCRIBE/NOTIFY mechanism as specified in RFC 3265.
BLF Subscription
When you configure the IP phone to monitor a specific line, the phone sends a SUBSCRIBE request with Request-
URI containing the monitor line URI to the server, and then receives a NOTIFY request. The NOTIFY message con-
tains an XML body with the status of the specific monitored line.
The following example shows a NOTIFY message for a BLF line “012”:
<?xml version="1.0"?>
<dialog-info xmlns="urn:ietf:params:xml:ns:dialog-info" version="1" state="full" entity-
y="sip:012@10.20.10.42:5060">
<dialog id="0000" > <state > terminated</state > </dialog >
</dialog-info>
BLF List Subscription
When you configure the IP phone to monitor a list of specific remote lines, the phone sends a SUBSCRIBE request
with Request-URI containing the BLF List URI, and then receives a NOTIFY request. The NOTIFY message con-
tains an XML body with the status of each monitor line.
The following example shows a NOTIFY message for a BLF List, the BLF List contains 4605 and 4607:
<?xml version="1.0" <?xml version="1.0"?>
<list xmlns="urn:ietf:params:xml:ns:rlmi" xmlns="urn:ietf:params:xml:ns:rlmi" version="0" fullState="true">
<resource uri="sip:4605@pbx.yealink.com">
<name > 4605 Yealink</name>
<instance id="JQZxud2qeo" state="active" cid="8y35ri@broadworks"/>
</resource>
<resource uri="sip:4605@pbx.yealink.com">

Yealink SIP-T33P Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Wall mountable	Yes
Operating system installed	Linux
Lines quantity	4 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	4
Volume control	Buttons
Number of function keys	5
Display diagonal	2.4 \
Display resolution	320 x 240 pixels
Voice codecs	AGC, AJB, CNG, G.711a, G.711u, G.722, G.723.1, G.726, G.729, G.729A, PLC, VAD, iLBC
Security algorithms	AES, HTTPS
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
RJ-9 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (typical)	3 W
Power consumption (Power over Ethernet (PoE))	5 W
Number of handles included	1 pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	186 mm
Width	212 mm
Height	146 mm
