Yealink SIP-T57W Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
501
2-rtp-pkt-loopback, the RTP payload is re-encapsulated and the RTP packets are looped back with a
new payload type and format. This type of loopback applies to the encapsulated and direct packet
loopback. Any type of encoding-related functions must not be part of this type of loopback path.
3-rtp-media-loopback & rtp-pkt-loopback, the answer must include only one of these two loopback
types and should give preference to the first loopback-type in the SDP offer.
Default
3
Parameter
sip.pkt_loopback_mode <y0000000000xx>.cfg
Description
It configures the encapsulation mode of incoming RTP packet.
Note: It works only if “sip.loopback_type” is set to 2 (rtp-pkt-loopback).
Permitted
Values
1-encapsulated packet loopback, the entire incoming RTP packet is encapsulated as payload within
an outer RTP packet. The loopback source can generate statistics for one-way path performance up
to the RTP level for each direction of travel.
2-directed packet loopback, the loopback mirror copies the payload of the incoming RTP packet into a
new RTP packet. The packet source can compute only two-way path statistics from the direct loop-
back packet header.
3-encapsulated & directed, the loopback mirror loops back the incoming RTP packets using either the
encapsulated RTP payload format or the direct loopback RTP payload format.
Default
3
Parameter
sip.pkt_loopback_encapsulated_payload <y0000000000xx>.cfg
Description
It configures the value of dynamic payload for encapsulated RTP.
Note: It works only if “sip.pkt_loopback_mode” is set to 1 (encapsulated packet loopback).
Permitted
Values
Integer greater than 98
Default
112
Parameter
sip.pkt_loopback_directed_payload <y0000000000xx>.cfg
Description
It configures the value of dynamic payload for the direct loopback RTP.
Note: It works only if “sip.pkt_loopback_mode” is set to 2 (directed packet loopback).
Permitted
Values
Integer greater than 98
Default
113
Parameter
sip.loopback.auto_answer.mode <y0000000000xx>.cfg
Description
It enables or disables the phone to automatically answer the incoming loopback call.
Permitted
Values
0-Disabled
1-Enabled
Default
1
Cloud
Yealink CP920 phones support cloud feature. The Cloud enterprise administrator uses the Yealink VC Cloud man-
agement service to assign each user an individual Cloud account. For more information, refer to Yealink VC Cloud
Management Service Administrator Guide .
After registered with a Yealink Cloud account successfully, the phone will download the Cloud accounts information
from the server automatically.

Yealink SIP-T57W Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Security algorithms	AES, HTTPS, MD5, SRTP
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Volume control	Buttons
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	7 \
Display resolution	800 x 480 pixels
Front camera	No
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Voice codecs	G.722, G.723.1, G.726, G.729A, G.729B, iLBC

Weight and Dimensions

Depth	220 mm
Width	259.4 mm
Height	211 mm
