Yealink SIP-T58A User Manual

User Guide for SIP-T58V/A Smart Media Phone
296
If the forward on code or off code is configured, the IP phone sends the corresponding code to
the server when a certain action takes place. For example, if you set the Always Forward on code
to be *71 (may vary on different servers), and the target number to be 1234. When you enable
Always Forward on the IP phone, the IP phone sends *711234 to the server, and then the server
will enable Always Forward feature on the server side, hence being able to get the right status of
the extension.
Call forward is configurable via web user interface at the path Features->Forward & DND.
Note
To configure the forward authorized numbers via web user interface:
1. Click on Features->Forward & DND.
2. Select Enabled from the pull-down list of Forward Emergency.
3. Enter the numbers in the Forward Authorized Numbers field.
For multiple numbers, enter a comma between every two numbers.
4. Click Confirm to accept the change.
When call forward is enabled on the phone, the phone cannot forward incoming calls from the
numbers specified in the Forward Authorized Numbers field.
Note
To disable call forward in phone mode:
Do one of the following:
- Swipe down from the top of the screen or swipe left/right to go to the second idle screen.
Tap Settings->Features->Call Forward.
Tap the desired forwarding type.
You can also enter the SIP URI or IP address in the Forward To field. For more information on
using the SIP URI or IP address, refer to Placing Calls on page 260.
Call forward is local to the phone, and may be overridden by the server settings. Call forward on
code or off code may be different among servers. For more information, contact your system
administrator.
Forward authorized number is configurable via web user interface only.

Yealink SIP-T58A Specifications

General

Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Operating system version	5.1.1
Operating system installed	Android
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Bluetooth	No
Security algorithms	SRTP
Networking standards	IEEE 802.1x
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS, IPv4/IPv6, UDP/TCP/DNS-SRV
USB 2.0 ports quantity	2
Voice codecs	G.711Mu, G.711a, G.722, G.722.1, G.722.1C, G.723, G.726, G.729ab, iLBC
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Front camera resolution (numeric)	2 MP
Base station keys	27
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
Power consumption (typical)	1.9 W
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	220 mm
Width	259.4 mm
Height	239 mm
Package depth	293 mm
Package width	324 mm
Package height	128 mm
