NeoGate TA410/810 User Manual
31/51
4. Gateway
Click to access the gateway configuration page. Users can configure the
details of FXO ports, VoIP settings, gateway settings and advanced settings.
4.1 FXO Port List
4.1.1 FXO Port List
All the FXO ports are listed here. You can edit each FXO port by clicking the "Edit" button.
Figure III-4-1General Settings
>General
Table III-4-1 Description of FXO Port General Settings
Items
Description
General
FXO Port Name
The corresponding port.
Caller ID User account number.
Volume Settings Configure the volume for the FXO port, the default
setting is 40%.
Select the impedance of the analog line connected
to the FXO port. Here is the impedance value for
the settings:
0 - 600 Ohm ( North American )
1 - 900 Ohm
2 - 270 Ohm + (750 Ohm || 150nF) and 275 Ohm +
(780 Ohm || 150nF)
