NeoGate TA410/810 User Manual
32/51
AC Termination
Impedance
3 - 220 Ohm + (820 Ohm || 120nF) and 220 Ohm +
(820 Ohm || 115nF)
4 - 370 Ohm + (620 Ohm || 310nF)
5 - 320 Ohm + (1050 Ohm || 230nF)
6 - 370 Ohm + (820 Ohm || 110nF)
7 - 275 Ohm + (78 Ohm || 150 nF)
8 - 120 Ohm + (820 Ohm || 110 nF)
9 - 350 Ohm + (1000 Ohm || 210nF)
10 - 0 Ohm + (900 Ohm || 30nF)
11 - 600 Ohm + 2.16 uF
12 - 900 Ohm + 1 uF
13 - 900 Ohm + 2.16 uF
14 - 600 Ohm + 1 uF
15 - Global complex impedance
VoIP Serer
Template
Primary Server
Choose the Primary VoIP server, where the
account will be registered.
Failover Server
Choose the failover server for the account.This
server will be used if the p
rimary server is
unavailable.
User Name
Username of the account. Used for VoIP trunk
registration. The user name should be entered if
the "Enable Register" is checked on the VoIP
Server.
Authentication
Name
Used for SIP authentication. The authentication
name should be entered if "Enable Register" is
checked on the VoIP Server.
Password
Password of the SIP account.
The password
should be entered if "Enable Register" is checked
on the VoIP Server.
From User
All outgoing calls from this SIP Trunk will use the
"From User" (in this case the account name for SIP
Registration) in From Header of the SIP Invite
package. Keep this field blank if not needed.
Online Number
Define the online number that expected by “Skype
Connect”and some other SIP service providers.
Leave this field blank if not needed.
