NeoGate TA410/810 User Manual
5/51
Application Description
Connect IPPBX and NeoGate TA FXO Gateway
NeoGate TA FXO gateway is a solution to extend FXO ports for your IPPBX.
Two modes are available for you to connect IPPBX and NeoGate TA FXO gateway, we
call them VoIP mode and SPS (Service Provider SIP)/SPX (Service Provider IAX) mode.
VoIP Mode:
The FXO port will be registered as one the VoIP server's SIP extensions if "Enable
Register" is checked on VoIP Server template.Select the VoIP Server template on the
FXO port page, and fill in the information like SIP username and password. After
registeration, if you want to call from IPPBX, you should call the registered SIP account,
and NeoGate TA will route the call to the PSTN line.
SPS/SPX Mode:
If "Enable Register" is not checked
, the FXO port will be registered as a SPS/SPX trunk to
the VoIP Server. One SPS/SPX trunk to NeoGate TA also should be created on the VoIP
Server. If you want to call from IPPBX, the number you dial should match the dial pattern
set on IPPBX outbound route. After receiving the call, NeoGate will forward it on the FXO
line to the destination number.
Figure II-1 Connect TA810 and IPPBX
For incoming calls from the PSTN to NeoGate TA, NeoGate TA will forward the call to a
configured SIP extension or to an inbound destination of IPPBX like IVR.
