Software Updates:
Details related to software updates are available online at www.yellowjacket.com or by
contacting Ritchie Engineering. See Chapter 1 for contact information.
Chapter 7:
Device Specifications
Table 7-1: Physical Specifications
Maximum Pressure
700 psia (48.3 bar)
Operating Temperature
140 to -4°F (60 to -20°C)
Storage Temperature
140 to -4°F (60 to -20°C)
Battery Life
4 hrs continuous Backlight
80 hrs no Backlight
Size
Approx. 7.5" x 8.5" x 4.25"
Weight
2.63 lbs
Table 7-2: Instrument Specifications
Working Pressure
0 – 700 psia (48.3 bar)
Pressure Sensing Resolution
0.1 psi, 0.1 bar, 1 kPa
0.001 MPa, 0.01 kg/cm^2
Pressure Sensing Accuracy
0.5% of full scale at 77°F (25°C)
1% of full scale 55 to 130°F (13 to 54°C)
2% of full scale -40°F to 248°F (-40 to 120°C)
Temperature Sensing Range
Sensing element: -40 to 266°F (-40 to 130°C)
Max Cord temp: 176°F (80°C)
Max Clamp Temp: 203°F (95°C)
Temperature Sensing Resolution
0.1°F or °C
Temperature Sensing Accuracy
±0.36°F (±0.2°C)
Vacuum Sensing Range
5 to 100000 microns
Vacuum Sensing Resolution
1 micron
