5-8 IM 04P02B01-01E
Note
• The displayable/printable range of scale values is –19999 to 30000 excluding the decimal.
• If the leftmost value of the scale is set to –20000 (excluding the decimal) and the low-cut
value is set to –20000, the value when the low-cut function is applied is displayed as “–Over.”
Skip (Unused Channels)
Select Skip.
Set the channel range.
The new setting takes effect.
First channel
Last channel
ESC/?
Set=Range
CH=01-01
Mode=Skip
01-01 Channel
Setting complete
Note
Do not use channels set to skip as a reference channel of delta computations or in computing
equations of the computation function (/M1 option).
5.1 Setting the Input range
To Next Page
