YOKOGAWA AQ6375E User Manual

iii
IM AQ6375E-02EN
Checking the Contents of the Package
Unpack the box, and check the following before operating the instrument. If the wrong items have
been delivered, if items are missing, or if there is a problem with the appearance of the items,
contact your nearest YOKOGAWA dealer.
AQ6375E Main Unit
Check that the model and suffix on the name plate on the rear of the instrument match those of
your order. When contacting the dealer from which you purchased the instrument, please give them
the instrument number.
Model Suffix Code
1
Specifications
AQ6375E AQ6375E Optical Spectrum Analyzer
Specification -01
-10
-20
Limited model
Standard Model
Extended model
Built-in light
source
-L1 Wavelength reference source
Power Cord
2
-D UL/CSA standard and PSE compliant, Rated Voltage: 125 V
-F VDE/Korean standard, Rated Voltage: 250 V
-R Australian standard, Rated Voltage: 250 V
-Q British standard, Rated Voltage: 250 V
-H Chinese standard, Rated Voltage: 250 V
-N Brazilian standard, Rated Voltage: 250 V
-T Taiwanese standard, Rated Voltage: 125 V
-B Indian standard, Rated Voltage: 250 V
-U IEC Plug Type B, Rated Voltage: 250 V
-Y No power cord included.
3
1 For products whose suffix code contains “Z,” an exclusive manual may be included. Please read it along
with the standard manual.
2
Make sure that the attached power cord meets the designated standards of the country and area that you
are using it in.
3
Prepare a power cord that complies with the standard specified by the country or region that the instrument
will be used in.
• No. (Instrument Number)
When contacting the dealer from which you purchased the instrument, please give them the
instrument number.
