1-19
Features
IM CA500-01EN
1
Function2 Information
Saved Data Notes
Source value
Function
Range
0% value
100% value
Sweep setting* Interval time
Repeat
Saving Data ON/OFF
Temperature
setting
Thermocouple terminal TC-A/TC-B
TC-B RJC setting ON/OFF
Burnout setting ON/OFF
TC scale standard setting IPTS-68/ITS-90
Temperature unit °C
Frequency setting Amplitude voltage setting
Pulse count setting
TC measurement
settings
0% value
100% value
Contact output setting ON/OFF
* Not saved when using the SAVE key.
Loading Data
Specify the memory number containing the saved data to load the information. The instrument
settings are changed to the loaded settings.
Measured value and source value are shown in the Function1 and Function2 display positions.
1.6 Saving and Loading CA500 Data
To Next Page
