5-9
IM CA500-01EN
1
2
3
4
5
6
7
Index
Saving Data
5.4 Copying Saved Data to a PC (CA550)
Procedure
1.
Connect this instrument to a PC through USB. This instrument is displayed as a USB storage
device on the PC.
2.
Copy the necessary data to the PC.
Description
CSV data saved on the CA550 can be copied to a PC.
Folder Structure
The following figure shows the CA550 folder structure.
Root
SaveData
SweepData
CalibrationData
Data saved with the SAVE key is saved.
Measurement/source data (.csv) of program
sweeps is saved.
Measurement/source data (.csv) of step
sweeps is saved.
Note
Data cannot be written to or deleted from the CA500 internal memory from a PC.
The CA550 internal memory information displayed on the PC is not updated automatically. To update the
information, remove the USB cable, or restart the CA550.
USB Interface Specifications
Electrical and mechanical specifications Complies with USB Rev.1.1
Connector Type B connector (receptacle)
Number of ports 1
Power supply Self powered, bus powered
PC system requirements A PC running Windows 8.1 or Windows 10 with a standard USB
port.
CDC(Communication Device Class)
This instrument uses CDC to communicate with a PC.
If the operating system of the PC connected to this instrument is Windows 8.1, you need to install a
CDC system definition file for YOKOGAWA products in the PC.
For details on how to obtain the system definition file, access the following YOKOGAWA’s webpage,
and download the file.
This is not necessary on Windows 10.
https://www.yokogawa.com/jp-ymi/tm/F-SOFT/
File name: YKCDC system definition file
