Source
Description
Source Range (RTD Type)
You can select from the following 14 RTD types.
RTD Measurement range
PT100 (PT100 JIS (3851)) -200.0°C to 800.0°C
JPT100 (PT100 former JIS (3916)) -200.0°C to 510.0°C
PT100 (3850) -200.0°C to 630.0°C
PT100 (3926) -200.0°C to 630.0°C
PT200 -200.0°C to 630.0°C
PT500 -200.0°C to 630.0°C
PT1000 -200.0°C to 630.0°C
Cu10 -100.0°C to 260.0°C
Ni120 -80.0°C to 260.0°C
PT50 -200.0°C to 630.0°C
PT50G -200.0°C to 800.0°C
PT100G -200.0°C to 630.0°C
Cu50M -180.0°C to 200.0°C
Cu100M -180.0°C to 200.0°C
Match the RTD type of this instrument to that of the measuring instrument.
Note
If the excitation current exceeds the upper limit, the source value display blinks.
2.5 Resistance Source Corresponding to the RTD Temperature
